Shelly PM Mini Gen3 is a small form factor power meter. Enhanced with all the gen2 firmware flexibility, it provides professional integrators with additional options for end-customer solutions. It can work standalone in a local Wi-Fi network, or it can also be operated through cloud home automation services through MQTT, HTTP, and WebSocket. All inbound connections support TLS. The device is an improved version of Shelly Plus PM Mini with a more advanced processor and increased memory.
Shelly PM Mini Gen3 can be accessed, set up, and monitored remotely by the User, as well as the Device can access and communicate with an automation system, as long as they are in the same network infrastructure.
The Device has an embedded Web Interface which can be used to monitor and control the device, as well as adjust its settings.
Main features
Power Meter: Designed as a small form factor power meter, allowing you to monitor the power consumption of connected devices.
Enhanced Firmware Flexibility: Inherits the flexibility of gen2 firmware, providing professional integrators with additional options for end-customer solutions.
Compact size: PM Mini Gen3 can be connected in very tiny spaces, unreachable for other devices.
Improved Processor and Memory: Upgraded with an improved processor and increased memory for enhanced performance.
Remote Access: Can be accessed, set up, and monitored remotely by the user, as well as communicate with an automation system within the same network infrastructure.
Embedded Web Interface: Features an embedded web interface for monitoring, control, and adjustment of settings.
BLE Gateway: Bridge between your Shelly BLU devices and the wider Shelly ecosystem. It receives Bluetooth signals and sends them to the cloud or locally to another non-bluetooth device.
WiFi Range extender for IoT devices: A WiFi extender is employed to expand the reach of your WiFi network by receiving your current WiFi signal, enhancing its strength, and then transmitting the enhanced signal over a wider area.
Wide range of integrations: The device can be integrated with 3rd party home systems, documented HTTP API, MQTT(s), Web Hooks over HTTP and HTTPS, UDP
Use cases
Power Consumption Monitoring: The primary purpose is to monitor the power consumption of connected devices in real-time. This information can be valuable for understanding energy usage patterns and making informed decisions to reduce consumption.
Energy Efficiency Optimization: Identify energy-hungry appliances and optimize their usage to improve overall energy efficiency in your home or workspace.
Appliance Health Check: Keep track of the power usage of individual appliances to assess their health and performance over time. Sudden spikes or changes in power consumption may indicate issues with the appliance.
Cost Management: With the knowledge of power consumption, you can estimate the cost of running specific devices and manage your electricity expenses more effectively.
Space-Efficient Retrofitting: Integrate the device into standard electrical wall boxes, behind power sockets, light switches, or other locations with limited space.
Remote Monitoring: Like the Shelly 1PM Mini Gen3, the PM Mini Gen3 also supports remote access. This allows you to monitor power consumption even when you're away from home.
这些迷你继电器专为方便使用而设计，具备标准开关的所有功能，却采用紧凑省空间的外形。尽管体积小巧，Shelly Mini Gen3 设备在性能和功能上毫不妥协。配备我们强大的 Shelly 芯片，拥有 8MB 内存，设备的效率和响应速度大幅提升，确保运行更加流畅和迅速。
Wi-Fi 操作
将Shelly PM Mini Gen3连接到您的Wi-Fi网络。无需HUB！
Bluetooth
通过Bluetooth快速接入，或将其用作Bluetooth网关。
电力监测
提供精确的电力消耗计量，帮助您节省开支。
URL 操作
让Shelly PM Mini Gen3直接控制其他智能设备。
脚本编写
Shelly PM Mini Gen3 完全支持 mjS 脚本编写，允许您创建自定义功能和特性。
解决方案
Shelly PM Mini Gen3
预防性监控
预防性监控
当电器设备出现故障时，它并不会直接停止工作。通常情况下，它会为了弥补其运行能力而增加能耗。由于其性能表面上没有明显变化，可能需要几个月才能发现问题，导致效率低下和能源浪费。Shelly PM Mini Gen3 可以安装在您需要的任何地方，并能立即报告能耗的增加，帮助您节省维修或更换设备的额外开支。
功耗分析以优化成本
功耗分析以优化成本
我们在夜间未使用的所有已连接电器或遗忘未关的灯都会产生不必要的能耗。Shelly PM Mini Gen3 的智能能耗计量功能将帮助您识别并消除家中或设施内每个已连接设备的多余能耗。结合智能场景，您可以利用 Shelly PM Mini Gen3 的数据来设置自动化场景，例如在用电高峰时关闭设备以保护它们，或在夜间关闭设备以节省能源。
