Shelly BLU Wall Switch 4 + Gira/Merten 适配器

Name: Shelly BLU WS4 + Gira/Merten 适配器
Brand: Shelly Europe
SKU: FGSKSBWS4_GM
Price: 14.90 EUR
Availability: InStock

Device image

Device identification

Device name: Shelly BLU Wall Switch 4
Device model: SBBT-004CEU
Device Bluetooth ID: 0x0006

Short description

Shelly BLU Wall Switch 4 (the Device) is a smart four-button Bluetooth control interface. It can be mounted seamlessly with various standard switch ranges. It can also be used as a standalone remote control. The Device features a long battery life, supports multi-click and strong encryption.

Main features

Long battery life
Supports multi-click
Compact size, portability, and ease of use
Strong encryption

Use cases

Lighting control: Assign the button to control specific lighting scenes or individual smart lights. For example, a single press could turn on/off the lights, while a long-term press could dim or brighten them.
Garage door opener: Use the strong encryption of Shelly BLU Wall Switch 4 and control your smart garage door opener as you approach or leave your garage.
Smart blinds or curtains: Open or close motorized blinds or curtain at the touch of a button.
Location-based automation: Set the device in Beacon mode so that to trigger specific actions when you come within Bluetooth range. Use the Device for presence control, for example to keep lights on while you need to spend some time in a certain area.
Scene control: Use the 4 buttons to activate any scene or specific actions you can imagine. Each button supports single, double, triple and long push - which allows the user to make 16 different actions!
Mix and match your interior design with the wide number of 3rd party frames supported
No wiring needed

Connectivity

Bluetooth Low Energy (BLE)

User interface

Inputs

Four push buttons
- Press and hold any two buttons simultaneously for 10 sec to pair Shelly BLU Wall Switch 4 with another Bluetooth device.
- Press and hold any button for 30 sec to factory reset (possible only shortly after inserting the battery).

Specifications

Quantity	Value
Physical
Size (HxWxD):	46x46x13 mm / 1.81x1.81x0.51 in
Weight:	17 g / 0.6 oz
Shell material:	Plastic
Shell color:	Ivory
Environmental
Ambient working temperature:	-20 °C to 40 °C / -5 °F to 105 °F
Humidity:	30% to 70% RH
Electrical
Power supply:	1x 3 V battery (included)
Battery type:	CR2032
Estimated battery life:	Up to 2 years
Bluetooth
Protocol:	4.2
RF band:	2400 - 2483.5 MHz
Max. RF power:	< 4 dBm
Range:	Up to 30 m / 100 ft outdoors, up to 10 m / 33 ft indoors (depending on local conditions)
Encryption:	AES (CCM mode)
